Description
Dimensions
Overall Length: 2529.84mm
Overall Width: 1272.54mm
Height To Top Of Cab: 1808.48mm
Wheelbase: 1752.6mm
Ground Clearance: 254mm
Drum Diameter – Front: 701.04mm
Drum Diameter – Rear: 701.04mm
Specifications
Steering System
System: Oscillatory Articulation
Steering Method: Hydrostatic
Oscillating Angle: 2.77777777777778degrees
Steering Angle: 32degrees
Engine
Number Of Cylinders: 3
Cooling Method: Water
Engine Make: Kubota
Engine Model: D1803
Gross Power: 24.6kw
Power Measured @: 2600rpm
Operational
Operating Weight: 2700.3kg
Fuel Capacity: 34.9L
Max Speed: 10km/h
Operating Voltage: 12V
Drum
Drum Width: 1198.9mm
Static Linear Load: 11.3kg/cm
Vibration Frequency 1: 63Hz
Nominal Amplitude – High: 0.6mm
Vibration Frequency 2: 67Hz
Centrifugal Force – High: 41kN
Weights
Grossweight: 3500kg
Brakes
Parking Brake: Hydromec
Service Brake: Hydrostatic
We specialize in selling high-quality used construction machines that have undergone rigorous inspections to ensure their reliability.
Each machine is backed by a 1-year warranty for good operation, providing you with peace of mind. This warranty is honored at authorized service centers, ensuring professional maintenance and support.
Our commitment to quality and customer satisfaction sets us apart in the industry.
By choosing our used machines, you benefit from both affordability and reliability.
